206 Tail Rotor Flap Stop Work Aid

No reviews yet Write a Review

This item is 3D printed, made out of PLA. Color may vary.

This work aid was designed to replace the Bell designed fork shaped lockout work aid.

The 206 tail rotors are shimmed between the tailrotor hub and flap stop.

That means every tailrotor is slightly different and the old design is not ideal.

With this work aid, you install it on the inboard side of the tailrotor hub on the shaft.

Since the inboard side doesn't rely on any shimming, it will work perfectly every time.

Comes with a red streamer to remind everyone to remove it before flight.

P/N: 206TFL-L

Works on all L-models and B-model with P/N 206-040-439-001 shaft

P/N: 206TFL-B

Low Altitude P/N 206-040-407-007 on B model aircraft


206B series aircraft have 2 P/N's of tail rotor output shafts. P/N 206-040-407-007 is the short shaft for low altitude applications.

It is a different diameter from the high altitude P/N 206-040-439-001.

We have flap locks for both shafts but need to know which shaft you have.

ATA Chapter:
64-Tail Rotor
Maintenance Type:
